Excel Tools

 nareshs7984 ,To further address the described bug, we suggest utilizing the Feedback feature to report this issue directly to the AppMarket team. Thanks.

 Mike Cichy Peter Lewis Appian AppMarket  April Schuppel  who should we contact regarding the above mentioned plugin issue. Not sure who is the owner of this plugin from Appian side.

What I see here no one is responding from Appian side for community member issue questions since last 10 months. Is any one from Appian is supporting this plugin?

Our project is impacted with the above mentioned. It would be great if some one review and fix this issue

 Peter Lewis  April Schuppel  @Appian AppMarket  @Apppin Support Team  @Appian Corporation

Read Excel File Paged (readexcelsheetpaging()) function is not reading excel file properly in one of the use case. Could you please review and fix this issue.

Use case and Steps to re-create:

• Create a simple Excel file with two columns(Two Headers)

• Add an simple Excel function to second column

  • The logic is, based on column 1 value conditionally populate second column value

  • Ex: =IF(A2:A100 = "", "-", IF(A2:A100<100, "TRUE","FALSE"))

• Populate the data in column 1 for this Template using Appian process (You can used Export CDT to Excel or Export SQL to Excel)

  • Note: I know the above mentioned smart services are deprecated, but those are working fine (You may already know about this as your the owner of the plugin and As community team members mentioned)

• Now use readexcelsheetpaging() to read the generated Excel file

  • It only returns the first column values, but the second column values coming as blank

    • Note1: Now download the same generated document from Appian to local desktop and open the file, you will see the column 1 and column 2 values properly.

    • Save the file and re-upload the file to Appian manually, now if we read the file using readexcelsheetpaging() it reads properly

• Note 2:  But if we use readexcelsheet function it is reading properly (But it is not recommend to use as it consumes to much system resources)

• I think there is an issue reading the file if it is generated in Appian, could you please review this and fix the issue.

Hi, I have a use case that if the readexcelsheet function has a parameter for stopping at a certain row limit, it would be perfect. how did you work around this issue?

Hi, I have a use case that if the readexcelsheet function has a parameter for stopping at a certain row limit, it would be perfect. how did you work around this issue?

@manishk114 is this issue resolved. I had 57 columns previously, which was working fine. Now I added one column and getting the same error!!!

You need to set exactly 58 parameters on the prepared statement

Hi Team,

We are facing a strange issue with CSV to DB

Summary -Issue with CSV to Db Smart service - CSV is not getting uploaded with more than 48 columns Previously we had 48 columns in the csv , and it was working fine , Later we had a new requirement to add new column, after adding the 49 column it stops working and showing error as attached. We have done few digging and found that if we remove any one column ( either new one or any another one), and remove the same in column mapping in the column parameter of the csv to DB smart service it works fine . Until we keep the column count within 48 all works well .

While checking the documentation , I can see that we can see the generated logs of this plugin , Can you please help how to get the logs of its prepare statement.

I can see below error in tomcat logs-

ERROR ImportCsvToDatabase8 Error executing SQL
java.sql.SQLSyntaxErrorException: (conn=3176834) You need to set exactly 48 parameters on the prepared statement
at org.mariadb.jdbc.internal.util.exceptions.ExceptionFactory.createException(ExceptionFactory.java:62)
at org.mariadb.jdbc.internal.util.exceptions.ExceptionFactory.create(ExceptionFactory.java:176)
at org.mariadb.jdbc.ClientSidePreparedStatement.addBatch(ClientSidePreparedStatement.java:256)
at sun.reflect.GeneratedMethodAccessor9526.invoke(Unknown Source)
at sun.reflect.DelegatingMethodAccessorImpl.invoke(DelegatingMethodAccessorImpl.java:43)
at java.lang.reflect.Method.invoke(Method.java:498)
at org.apache.tomcat.jdbc.pool.StatementFacade$StatementProxy.invoke(StatementFacade.java:118)
at com.sun.proxy.$Proxy218.addBatch(Unknown Source)
at com.appiancorp.ps.exceltools.util.DatabaseUtils.addBatchInsert(DatabaseUtils.java:594)
at com.appiancorp.ps.exceltools.util.CsvHelperUtils.importDataWithHeaderFromFile(CsvHelperUtils.java:181)
at com.appiancorp.ps.exceltools.smartservice.ImportCsvToDatabase8.processTheRequest(ImportCsvToDatabase8.java:90)
at com.appiancorp.ps.exceltools.smartservice.ImportCsvToDatabase8.run(ImportCsvToDatabase8.java:70)
at com.appiancorp.process.runtime.framework.DefaultActivityExecutor$1.lambda$call$0(DefaultActivityExecutor.java:136)
at com.appiancorp.plugins.PluginUsageLogger.runWithPluginInformation(PluginUsageLogger.java:54)
at com.appiancorp.process.runtime.framework.DefaultActivityExecutor$1.call(DefaultActivityExecutor.java:136)
at com.appiancorp.process.runtime.framework.DefaultActivityExecutor$1.call(DefaultActivityExecutor.java:130)
at com.appiancorp.common.ContextClassLoaderSwitcher.runInContext(ContextClassLoaderSwitcher.java:27)
at com.appiancorp.process.runtime.framework.DefaultActivityExecutor.execute(DefaultActivityExecutor.java:130)
at com.appiancorp.process.engine.UnattendedJavaActivityRequest.execute(UnattendedJavaActivityRequest.java:88)
at com.appiancorp.process.engine.UnattendedJavaActivityRequestResponseCreator.getJavaActivityResultResponse(UnattendedJavaActivityRequestResponseCreator.java:22)
at com.appiancorp.process.engine.UnattendedJavaActivityRequest.getJavaActivityResultResponse(UnattendedJavaActivityRequest.java:67)
at com.appiancorp.process.engine.UnattendedJavaActivityRequest.execute0(UnattendedJavaActivityRequest.java:55)
at com.appiancorp.common.persistence.data.AppianDataUserContextProvider.executeWithConsistentDataReads(AppianDataUserContextProvider.java:143)
at com.appiancorp.process.engine.ProcessContinuationRequest.executeOuter(ProcessContinuationRequest.java:68)
at com.appiancorp.process.engine.ContinuationRequest.execute(ContinuationRequest.java:129)
at com.appiancorp.process.workpoller.UnattendedRequestHandlerBean.onMessage(UnattendedRequestHandlerBean.java:36)
at com.appiancorp.process.workpoller.WorkItem.run(WorkItem.java:110)
at org.springframework.jca.work.SimpleTaskWorkManager$DelegatingWorkAdapter.run(SimpleTaskWorkManager.java:241)
at java.util.concurrent.ThreadPoolExecutor.runWorker(ThreadPoolExecutor.java:1149)
at java.util.concurrent.ThreadPoolExecutor$Worker.run(ThreadPoolExecutor.java:624)
at java.lang.Thread.run(Thread.java:750)

Hi ,

We are seeing issue with  Import CSV to Database smart service if number of columns are more than 48 columns.

Do we have any limit in terms of number of columns which can import successfully.

Thanks

We are using Excel Tool v2.2.11. We want to handle a use case where User uploads unreadable / corrupted Excel file from UI using a!fileUploadField(). We are using readexcelsheet() function to read the file but it gives Expression Evaluation Error.

Please suggest how to catch this expression evaluation error thrown by readexcelsheet() function when trying to read unreadable/ corrupted Excel sheet. We want to delete this document (if its unreadable) & show an error message to user that the uploaded document is unreadable.

PFB screenshot showing the error thrown by readexcelsheet():

• Replace deprecated content APIs with modernized file management APIs. See the 23.2 Release notes here docs.appian.com/.../Appian_Release_Notes.html
