I have created a web api for uploading documents into appian application
a!localVariables( local!body:http!request.body, local!key: http!request.pathSegments, local!keyNumber:regexfirstmatch(pattern: "\d+", searchString: local!key), local!requestStructure: rule!PRE_FormatRcoDocumentRequestFromMyWorldRequest(jsonRequest: todocument(local!body), key: local!key), if( or( a!isNullOrEmpty(local!requestStructure), a!isNullOrEmpty(local!key) ), a!httpResponse( statusCode: 400, headers: { a!httpHeader( name: "Content-Type", value: "application/json" ) }, body: a!toJson(a!map(error: local!requestStructure)) ), a!startProcess( processModel: cons!PRE_PM_UPLOAD_DOCUMENTS, processParameters: { uploadDocuments:local!requestStructure, intakeMain:'recordType!{9228ede4-797f-443e-ba77-59aeed242b7a}PRELUDE Intake Main'( 'recordType!{9228ede4-797f-443e-ba77-59aeed242b7a}PRELUDE Intake Main.fields.{61b2bc9e-c8e3-4635-bde7-b9c829a75682}idIntakeMain': local!key ) }, isSynchronous: true(), onSuccess: a!httpResponse( statusCode: 200, headers: { a!httpHeader( name: "Content-Type", value: "application/json" ) }, body: if( a!isNotNullOrEmpty(fv!processInfo), a!toJson( { rule!PRE_CreateResponseForMyWorldRcoComment(fv!processInfo.pv.RecordsUpdated), } ), null() ) ), onError: a!httpResponse( statusCode: 500, headers: { a!httpHeader( name: "Content-Type", value: "application/json" ) }, body: a!toJson( { error: "There was an error starting the process" } ) ) ) ), )
In this scenario png file is getting converted as txt and following text is getting added into the file(I have attached the file for more clarification)
--TnQmfygKfP801A_kE1bGL-7YAFk_k6gl9 Content-Disposition: form-data; name="file"; filename="Profile Picture.jpg" Content-Type: image/png Content-Transfer-Encoding: binary
Discussion posts and replies are publicly visible
The docs mention that you need to define an HTTP header with the document name to be able to provide the file correctly - did you try that?
Yes if I pass Header as "Appian-Document-Name" : "Profile Picture.png" It will save the file with png extension but it will come as unsupported format
