PDF Utilities

Using this plug-in we can add:

  1. Header and Footer
  2. Image
  3. Watermark Text

Add Header and Footer Inputs

  • Source Document (Document) - The PDF file in which Header and Footer text should be added.
  • New Document Name (Text) - Name for the newly created PDF Document.
  • New Document Desc (Text) - Description of the output PDF Document.
  • Save In Folder (Folder) - Folder to which the output PDF Document will be saved.
  • Offset- X (Integer) - To specify the offset from the x-axis in the pixels (From the left margin and maximum allowed offset is less than 200).
  • Font Size (Integer) - To specify the font size for Header and Footer Text (Max Size 40).
  • Header Text (Text) - Header Text to be written in the PDF.
  • Footer Text (Text) - Footer Text to be written in the PDF.

Insert Image In PDF Inputs

  • Source Document (Document) - The PDF file in which image to be inserted.
  • Image (Document) - The Image file to be added in PDF.
  • New Document Name (Text) - Name for the newly created PDF Document.
  • New Document Desc (Text) - Description of the output PDF Document.
  • Save In Folder (Folder) - Folder to which the output PDF Document to be saved in.
  • Page Number (Integer) - In which page the image should be added (Zero Based Index).
  • Height (Integer) - Height of the image while inserting into the PDF (Should not be zero).
  • Width (Integer) - Width of the image while inserting into the PDF (Should not be zero).
  • X-Coordinate - X-axis position in the given page number where image to be inserted into the PDF.
  • Y-Coordinate - Y-axis position in the given page number where image to be inserted into the PDF.

Add Watermark Text Inputs

  • Source Document (Document) - The PDF file in which Watermark text to be added.
  • New Document Name (Text) - Name for the newly created PDF Document.
  • New Document Desc (Text) - Description of the output PDF Document.
  • Save In Folder (Folder) - Folder to which the output PDF Document to be saved in.
  • Offset-X (Integer) - To specify the offset from the x-axis in the pixels(From the left margin).
  • Offset-Y (Integer) - To specify the offset from the y-axis in the pixels(From the Top margin).
  • Font Size (Integer) - To specify the font size for Watermark Text (Max Size 50).
  • Watermark Text (Text) - Watermark Text to be inserted in the PDF.

Outputs for all Smart Services

  • New Document Created (Document)  - The output PDF file.
  • Error Message (Text) - Error message received.
  • Error Occurred (Boolean) - Set to true if there is an occurrence of an error.
