I
iswaryan3520
September 3, 2025
Question

Expression evaluation error at function a!gridField : A grid component has an invalid value for "userFilters". "userFilters" and "showSearchBox" may only be specified when the when "data" is sourced from recor

  • September 3, 2025
  • 11 replies
  • 0 views

I am getting above error, I have a doubt for now I am using record data function to get the data and using it as a source for grid component.  i tried changing source to result to queryrecordtype  instead of recorddata also . so as this message suggest  Do I need to directly reference the recordtype in the data field of grid component?

11 replies

stefanhelzle0001
stefanhelzle0001
September 3, 2025

Can you share your code?

I
iswaryan3520Author
September 3, 2025

This is the variable I am saving the result

 local!data:rule!WMS_AllTasksBasedOnRequest(
    clientId: ri!wmsClient['recordType!{f4cd7e71-921f-4b1a-b85d-75f79a3f5fad}WMS Client.fields.{98e00a2b-6fa6-4873-a07f-94b7aa3e111b}clientId'],
    requestID: ri!requestID
  ),
This the code inside the rule

if(
  and(
    a!isNotNullOrEmpty(ri!requestID),
    a!isNotNullOrEmpty(ri!clientId)
  ),
  a!recordData(
    recordType: 'recordType!{8ad84fc9-2626-4a24-96c1-facc97b02acf}WMS Task',

    filters: a!queryLogicalExpression(
      operator: "AND",
      logicalExpressions: {
        a!queryLogicalExpression(
          operator: "OR",
          logicalExpressions: {
            a!queryLogicalExpression(
              operator: "AND",
              filters: {
                a!queryFilter(
                  field: 'recordType!{8ad84fc9-2626-4a24-96c1-facc97b02acf}WMS Task.relationships.{d360027c-a72d-4cf4-8da1-64e5fc391a77}aoRequestMaster.fields.{f91b1837-e0b1-40ce-b1ed-82c5575133e8}clientId',
                  operator: "=",
                  value: ri!clientId
                ),
        )
        }
),

a!queryLogicalExpression(
          operator: "AND",
          filters: {
            a!queryFilter(
              field: 'recordType!{8ad84fc9-2626-4a24-96c1-facc97b02acf}WMS Task.fields.{7bd950c9-0815-4b17-9142-2d3c80fc8a27}statusId',
              operator: "not in",
              value: {
                cons!WMS_REF_ID_TASK_STATUS_NOT_APPLICABLE,
                cons!WMS_REF_TYPE_ID_TASK_STATUS_COMPLETED
              },

            )
          }
        ),
        a!queryLogicalExpression(
          operator: "AND",
          filters: {
            a!queryFilter(
              field: 'recordType!{8ad84fc9-2626-4a24-96c1-facc97b02acf}WMS Task.fields.{9c423b5a-38cd-40f9-bf2e-40ec57a2c572}entityId',
              operator: "=",
              value: ri!requestID,

            ),

          }
        ),

      },
      filters: {}
    ),

  ),
  null
)

This is where I am using that result

 a!gridField_24r3(
      labelPosition: "ABOVE",
      data: local!data,
      a!gridColumn(
          label: cons!WMS_LABEL_TASK_STATUS,
          value: rule!WMS_DisplayTags(
            fv!row['recordType!{8ad84fc9-2626-4a24-96c1-facc97b02acf}WMS Task.relationships.{9c3378ff-9320-498b-80f3-f2c1e21cad09}wfmRefLookupTaskStatus.fields.{6f78955b-86b9-4b45-9319-b5e8ecb6c42c}value']
          ),
          align: "START"
        ),
         a!gridColumn(
          label: cons!AO_LABEL_ASSIGNEE,
          sortField: 'recordType!{8ad84fc9-2626-4a24-96c1-facc97b02acf}WMS Task.fields.{5dae0b96-9faf-45a6-956a-da18b35909aa}assignedToUser',
          value: if(
            a!isNotNullOrEmpty(
              fv!row['recordType!{8ad84fc9-2626-4a24-96c1-facc97b02acf}WMS Task.fields.{5dae0b96-9faf-45a6-956a-da18b35909aa}assignedToUser']
            ),
            rule!WMS_getUserFullName(
              fv!row['recordType!{8ad84fc9-2626-4a24-96c1-facc97b02acf}WMS Task.fields.{5dae0b96-9faf-45a6-956a-da18b35909aa}assignedToUser']
            ),
            if(
              a!isNotNullOrEmpty(
                tointeger(fv!row['recordType!{8ad84fc9-2626-4a24-96c1-facc97b02acf}WMS Task.fields.{699be1a8-928c-4f3b-9858-eff2fa68a5c2}assignedToGroup'])
              ),
              if(
                fv!row['recordType!{8ad84fc9-2626-4a24-96c1-facc97b02acf}WMS Task.fields.{699be1a8-928c-4f3b-9858-eff2fa68a5c2}assignedToGroup'] = - 1,
                group(
                  tointeger(cons!WMS_GRP_ALL_USERS),
                  "groupName"
                ),
                group(
                  tointeger(
                    fv!row['recordType!{8ad84fc9-2626-4a24-96c1-facc97b02acf}WMS Task.fields.{699be1a8-928c-4f3b-9858-eff2fa68a5c2}assignedToGroup']
                  ),
                  "groupName"
                )
              ),
              "Not Assigned"
            )
          )
        ),
      initialSorts: a!sortInfo(
        field: 'recordType!{8ad84fc9-2626-4a24-96c1-facc97b02acf}WMS Task.fields.{c81dc625-972c-4d3c-83a1-6a50b02bf11b}updatedOn',
        ascending: false()
      ),
      validations: {},
      refreshAlways: true(),
      refreshAfter: "RECORD_ACTION",
      userFilters: {
        'recordType!{8ad84fc9-2626-4a24-96c1-facc97b02acf}WMS Task.filters.{73fa1c28-e15f-48b9-a484-c036362f960f}Task Status',
        'recordType!{8ad84fc9-2626-4a24-96c1-facc97b02acf}WMS Task.filters.{e5aae71f-5fc9-43a1-9905-ffbddd031bf8}Assignee'
      },
      showSearchBox: true(),
      showRefreshButton: true(),
      showExportButton: true(),
      emptyGridMessage: "No Data Found",
      showWhen: a!isNotNullOrEmpty(local!data),

    )
  }

stefanhelzle0001
stefanhelzle0001
September 3, 2025

I never tried to store a!recordData into a local and put that local into the grid. I think the idea is to use a!recordData directly in the grid data parameter. My understanding is, that the internal logic of the grid directly interacts with a!recordData.

shubhama926776
shubhama926776
September 3, 2025

Your rule might returns null when conditions aren't met. The grid's data parameter must always have record-sourced data when using userFilters/showSearchBox.
Never return null from your rule. Always return a!recordData(), even if it's filtered to return zero records when conditions aren't met.

I
iswaryan3520Author
September 3, 2025

Okay, then can I just remove the condition and add the ignoreFiltersWithEmptyValues set to true.

shubhama926776
shubhama926776
September 3, 2025

Yes, But Make sure, It will return ALL records (or records matching remaining filters) when values are empty.
Test the rule properly to ensure it returns recordData instead of null.
