Bot not able to recognize Image

I'm trying to create Image Recognition Bot using Low Code module but it is unable to search the image. I have tried with multiple images and with different configurations. Has anyone successfully searched the image?

mukeshr0002Answer
Inspiring
Sep 19, 2021 2:56 AM UTC

Hi Aparajita,

I have used this falcon module or low code module in few bots and all are working fine as of now.

Things to remember when using image automation:

- Your application opened by bot has to be in foreground when image automation action is getting executed.

-  Image captured via Appian Agent needs to be places in correct server path.

- Image captured in machine has to be of same resolution with the machine bot is running.

- If the image captured is unique in screen than you can reduce the tolerance and offset. Only if image is captured is not unique then try to have higher tolerance and offset or any other approach.

Regards,

Mukesh

View in thread

6 replies

danny.verb
danny.verb
Employee
Aug 30, 2021 3:38 PM UTC

Is your screen resolution set to 100%? docs.appian.com/.../falcon-module.html

aparajitas0001
aparajitas0001Author
Known Participant
Sep 1, 2021 8:23 AM UTC

Yes [mention:cd62cf79924f483cb1bf072c9026a3ec:e9ed411860ed4f2ba0265705b8793d05]. I was working through low code module before and tried searching for multiple images, I finally switched to Falcon Module and with a few settings for tolerance and colorTolerance. I was able to find image successfully!

I think it needs to be tested with different tolerance settings to finally find the image. I would still like to know if anyone has successfully used low code module.

mukeshr0002Answer
Inspiring
Sep 19, 2021 2:56 AM UTC

Hi Aparajita,

I have used this falcon module or low code module in few bots and all are working fine as of now.

Things to remember when using image automation:

- Your application opened by bot has to be in foreground when image automation action is getting executed.

-  Image captured via Appian Agent needs to be places in correct server path.

- Image captured in machine has to be of same resolution with the machine bot is running.

- If the image captured is unique in screen than you can reduce the tolerance and offset. Only if image is captured is not unique then try to have higher tolerance and offset or any other approach.

Regards,

Mukesh

    victorp9880
    New Participant
    Jun 16, 2023 1:52 AM UTC
    [deleted]
    sanchitg0002
    sanchitg0002
    Inspiring
    Jun 16, 2023 7:12 AM UTC
