Removing Legend Filter in Graph

  • May 3, 2023
  • 1 reply
  • 4 views

Is there any way to still keep the legend in a graph but remove the click on legend filter functionality? In this case I am referring to the Points legend; this is a sample graph I am playing around with in but I do not want the user to filter on legend in this case.

1 reply

S
sanchitg0002
Inspiring
May 4, 2023

This is not possible in chart Field configuration but you can add rich text component below chart and make it look like chartField's Legend.

a!localVariables(
  local!chartSeries: {
    a!map(label: "Point1", data: { 8.3, 3.02, 2.71 }),
    a!map(label: "Point2", data: { 8.3, 3.02, 2.71 }),
    a!map(label: "Point3", data: { 8.3, 3.02, 2.71 })
  },
  local!showLegend: false,
  {
    a!barChartField(
      categories: { "Baseball", "Hockey", "Soccer" },
      series: a!forEach(
        local!chartSeries,
        a!chartSeries(label: fv!item.label, data: fv!item.data)
      ),
      yAxisTitle: "Average Point per Professional Game",
      showLegend: local!showLegend,
      showDataLabels: true,
      colorScheme: "CLASSIC",
      showTooltips: false
    ),
    a!columnsLayout(
      columns: {
        a!columnLayout(
          contents: a!richTextDisplayField(
            labelPosition: "COLLAPSED",
            value: a!forEach(
              local!chartSeries.label,
              {
                a!richTextIcon(
                  icon: "circle",
                  color: "SECONDARY",
                  size: "SMALL"
                ),
                a!richTextItem(text: "  " & fv!item & "     ", size: "SMALL")
              }
            ),
            align: "CENTER"
          ),

        )
      },
      spacing: "NONE",
      showWhen: not(local!showLegend)
    )
  }
)
